STICKER LABELLING MACHINE

Atria’s Sticker Labelling Machine range is designed for high-precision self-adhesive label application across various bottle shapes and packaging formats. Engineered for pharmaceutical, nutraceutical, cosmetic, and food industries, the machines ensure accurate label placement, wrinkle-free application, and stable high-speed performance.

The system is built with servo-controlled label dispensing mechanisms and PLC-based automation to guarantee consistent label positioning with minimal wastage. Designed as per cGMP standards, the machine integrates seamlessly with filling, capping, and secondary packaging systems.

The range includes dedicated and combination models for round, flat, and mixed bottle formats.

Technical Data

Products Description

Specification	APMSLM-R	APMSLM-SF	APMSLM-DF	APMSLM-SFR	APMSLM-C
Output Capacity	Up to 150 BPM	Up to 120 BPM	Up to 120 BPM	Up to 150 BPM	Up to 150 BPM
Bottle Type	Round	Flat Single Side	Flat Double Side	Flat Single Side + Round	Flat Single Side + Round
Label Type	Self-Adhesive	Self-Adhesive	Self-Adhesive	Self-Adhesive	Self-Adhesive
Label Width	Up to 150 mm	Up to 150 mm	Up to 150 mm	Up to 150 mm	Up to 150 mm
Bottle Diameter Range	25 – 100 mm	-NA-	-NA-	25 – 100 mm	25 – 100 mm
Bottle Height Range	50 – 250 mm	50 – 250 mm	50 – 250 mm	50 – 250 mm	50 – 250 mm
Label Dispensing Drive	Servo Motor	Servo Motor	Servo Motor	Servo Motor	Servo Motor
Accuracy	±1 mm	±1 mm	±1 mm	±1 mm	±1 mm
Power Supply	230V, 1 Phase, 50 Hz	230V, 1 Phase, 50 Hz	230V, 1 Phase, 50 Hz	230V, 1 Phase, 50 Hz	230V, 1 Phase, 50 Hz
Conveyor Height	850 ± 25 mm	850 ± 25 mm	850 ± 25 mm	850 ± 25 mm	850 ± 25 mm
Frame Construction	SS304	SS304	SS304	SS304	SS304
Control System	PLC + HMI	PLC + HMI	PLC + HMI	PLC + HMI	PLC + HMI
